| Catalogue No. |
Specification |
| 1151 BC/ES |
Die cast Aluminium body and die cast protective wire guard with clear U shape glass with rubber gasket, porcelain BC or ES holder, 2 way connector with 2 nos. cable entries with plastic cable glands. SS Hardware suitable upto 60W Lamp. |
| 1151 N/(BC/ES) |
60w BC/ES Holder Nylon Body and Guard With U Shape Clear Glass. 2 nos cable entries with plastic cable glands. |
| 2541 BC/ES |
Same as per 1151 with cast Brass body and Brass / SS wire guard. |
| 1171 BC/ES |
Same as per 1151 - suitable for side wall mounting arrangements with 2 nos. cable entries Brass glands opposite side. |
| 1171 N/(BC/ES) |
60w BC/ES Holder Nylon Body and Guard With U Shape Clear Glass suitable for side wall mounting. 2 nos cable entries with plastic cable glands. |
| 1371 BC/ES |
--- do --- cast Brass body with Brass / SS protective wire Guard. |
| 1181 BC/ES |
Cast Aluminium body with MS/SS protective wire guard with clear U shape threaded glass porcelain BC / ES lamp holder with 2 way connector with 2 nos. suitable upto 100W Lamp. |
| 1181 N/(BC/ES) |
100w BC/ES holder Nylon body and guard with U shape threaded clear glass. 2 nos cable Entries with plastic cable glands. |
| 1381 |
Same as per 1181 - Cast Brass body with Brass/ SS protective wire guard. |
| 1154 |
Cast Aluminium body with die cast Aluminium protective wire guard with clear U shape glass with rubber gasket. SBC Brass holder for 24V. 25W. pigmy lamp. 2 nos. cable entries with plastic cable glands. Fitting mainly useful for emergency LED Light Fittings. |
| 1354 |
---do--- cast Brass body. |
