Marine Flood Light Fitting





CAT. NO. 2690

CAT. NO. 2693

Products Details

Catalogue No. Specification
CAT. NO. 2690 Cast Aluminium body light fitting with clear toughened front glass with Aluminium ring with rubber gasket fitting with Aluminum polished reflector and MS bracket for movement and fixing the fitting. Porcelain ES (screw type) lamp holder. Suitable up to 100W. lamp.
CAT. NO. 2691 --do-- Suitable up to 200W. lamp.
CAT. NO. 2692 --do-- Suitable up to 300W. lamp
CAT. NO. 2693 --do-- Suitable up to 500W. lamp

Marine LED Flood Light Fitting

CAT. NO. 4005

CAT. NO. 4006

CAT. NO. 4010

Products Details

Catalog No. Watt Annual Power Consumption Max. Lumens
4001 30 W 90 KW 2700 Im
4002 45 W 135 KW 4430 Im
4003 60 W 180 KW 5920 Im
4004 80 W 240 KW 7930 Im
4005 100 W 305 KW 9780 Im
4006 150 W 460 KW 14730 Im
4010 200 W 580 KW 17600 Im
4011 250 W 750 KW 23050 Im
Specifications
4001 Die Cast Aluminium body LED Flood light fitting with clear toughened front glass with Die Cast Aluminium cover ring with rubber gasket. Fitting with Aluminium polished reflector, Fitting with MS bracket for Vertical movement and fixing the fitting. Suitable for 30W. 240V. LED with suitable Electronic Driver. Fitting in the line of IP 65 protection.
4002 Same as per above... But suitable for 45W. 240V.
4003 Same as per above... But suitable for 60W. 240V.
4004 Same as per above... But suitable for 80W. 240V.
4005 Same as per above... But suitable for 100W. 240V.
4006 Same as per above... But suitable for 150W. 240V.
4010 Same as per above... But suitable for 200W. 240V.
4011 Same as per above... But suitable for 250W. 240V.
